Atomos AtomX CAST for Ninja V
Choose PayGate at checkout for MobiCred Payments.
- Compact Quad HDMI Docking Station
- Converts Ninja V Monitor into Switch
- 4 x HDMI Inputs, Source Select Buttons
- Graphic Overlays, PiP, Streaming Output
- Mixed Resolution Output up to 1080p60
- Convert Progressive & Interlaced
- Mirror, Program, Preview, 4-Up Display
- UVC/Live Streaming with AtomX Connect
- Can Also Select with Monitor Touchscreen
- Output to Recording Device Supported
Orms Bellville
Orms Cape Town
Atomos AtomX CAST for Ninja V
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Compact Quad HDMI Docking Station
- Converts Ninja V Monitor into Switch
- 4 x HDMI Inputs, Source Select Buttons
- Graphic Overlays, PiP, Streaming Output
- Mixed Resolution Output up to 1080p60
- Convert Progressive & Interlaced
- Mirror, Program, Preview, 4-Up Display
- UVC/Live Streaming with AtomX Connect
- Can Also Select with Monitor Touchscreen
- Output to Recording Device Supported
Choose PayGate at checkout for MobiCred Payments.
- Compact Quad HDMI Docking Station
- Converts Ninja V Monitor into Switch
- 4 x HDMI Inputs, Source Select Buttons
- Graphic Overlays, PiP, Streaming Output
- Mixed Resolution Output up to 1080p60
- Convert Progressive & Interlaced
- Mirror, Program, Preview, 4-Up Display
- UVC/Live Streaming with AtomX Connect
- Can Also Select with Monitor Touchscreen
- Output to Recording Device Supported
The Atomos AtomX CAST for Ninja V is used to convert your Ninja V to a multi-camera studio. Allowing you to switch up to four HDMI video sources and output to a variety of destinations such as an external monitor, recorder, separate switcher, or live streaming computer. The Atomos AtomX CAST for Ninja V is well suited for a variety of applications including corporate, events, family occasions, house of worship or studio applications.
The unit mounts to the back of the Atomos Ninja V or and supports a variety of resolutions up to 1080p60 through four HDMI inputs. The monitor can view a single image, Picture-in-Picture, or 4-Up modes, and you can also add logos and graphic overlays. It can send Program, Preview, Picture-in-Picture, and 4-Up displays to the HDMI output. You will also find four buttons that can be programmed to your needs for specific shortcuts.
The Atomos AtomX CAST for Ninja V allows you to preview your broadcast while simultaneously outputting to a recorder, monitor, projector, or live streaming to a computer using the optional AtomX Connector.
The Atomos Cast uses the adapter included with the Atomos Ninja V to be powered. And it passes the power onto the monitor through the battery mount.
Note: This unit is not compatible with the Ninja V+ model.
Applications:
- Live Streaming
- Simultaneously Recording Live Events
- Multi-Camera Productions
- Corporate Events and Meetings
- Music, Awards, and Performance Events
- Weddings and Family Events
- Atomos AtomX CAST for Ninja V
- USB Type-C Cable
- AtomX SSD Mini Handle
General
Compatibility | Atomos Ninja V |
Video Resolution Supported | 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 1080i: 60, 59.94, 50 |
Tally Light | Yes |
Control | 4 x Source Select Buttons 4 x Programmable Function Buttons Ninja V Monitor Touchscreen |
Timecode | Yes, Embedded |
Cooling | Passive |
Mounting Interface | Battery Mount of Ninja V Monitor |
Display
Panel Type | LCD |
Size | Not Specified by Manufacturer |
I/O
USB | 1 x USB Type-C Female Output |
Video | 4 x HDMI Type A Input 1 x HDMI Type A Output |
Power
Power Source | AC Input |
DC Input Power | 6.2 to 16.8 VDC |
Physical
Mounting | Bottom: 1 x 1/4"-20 Bottom: 1 x 3/8"-16 |
Material of Construction | Plastic |
Dimensions | 160 x 129 x 49 mm |
Weight | 485 g |
