SHORT DESCRIPTION

  • Compact Quad HDMI Docking Station
  • Converts Ninja V Monitor into Switch
  • 4 x HDMI Inputs, Source Select Buttons
  • Graphic Overlays, PiP, Streaming Output
  • Mixed Resolution Output up to 1080p60
  • Convert Progressive & Interlaced
  • Mirror, Program, Preview, 4-Up Display
  • UVC/Live Streaming with AtomX Connect
  • Can Also Select with Monitor Touchscreen
  • Output to Recording Device Supported

    The Atomos AtomX CAST for Ninja V is used to convert your Ninja V to a multi-camera studio. Allowing you to switch up to four HDMI video sources and output to a variety of destinations such as an external monitor, recorder, separate switcher, or live streaming computer. The Atomos AtomX CAST for Ninja V is well suited for a variety of applications including corporate, events, family occasions, house of worship or studio applications.

    The unit mounts to the back of the Atomos Ninja V or and supports a variety of resolutions up to 1080p60 through four HDMI inputs. The monitor can view a single image, Picture-in-Picture, or 4-Up modes, and you can also add logos and graphic overlays. It can send Program, Preview, Picture-in-Picture, and 4-Up displays to the HDMI output. You will also find four buttons that can be programmed to your needs for specific shortcuts.

    The Atomos AtomX CAST for Ninja V allows you to preview your broadcast while simultaneously outputting to a recorder, monitor, projector, or live streaming to a computer using the optional AtomX Connector.

    The Atomos Cast uses the adapter included with the Atomos Ninja V to be powered. And it passes the power onto the monitor through the battery mount.

    Note: This unit is not compatible with the Ninja V+ model.

    Applications:

    • Live Streaming
    • Simultaneously Recording Live Events
    • Multi-Camera Productions
    • Corporate Events and Meetings
    • Music, Awards, and Performance Events
    • Weddings and Family Events

    • Atomos AtomX CAST for Ninja V
    • USB Type-C Cable
    • AtomX SSD Mini Handle

    General

    Compatibility Atomos Ninja V
    Video Resolution Supported 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98
    1080i: 60, 59.94, 50
    Tally Light Yes
    Control 4 x Source Select Buttons
    4 x Programmable Function Buttons
    Ninja V Monitor Touchscreen
    Timecode Yes, Embedded
    Cooling Passive
    Mounting Interface Battery Mount of Ninja V Monitor

    Display

    Panel Type LCD
    Size Not Specified by Manufacturer

    I/O

    USB 1 x USB Type-C Female Output
    Video 4 x HDMI Type A Input
    1 x HDMI Type A Output

    Power

    Power Source AC Input
    DC Input Power 6.2 to 16.8 VDC

    Physical

    Mounting Bottom: 1 x 1/4"-20
    Bottom: 1 x 3/8"-16
    Material of Construction Plastic
    Dimensions 160 x 129 x 49 mm
    Weight 485 g
