Atomos Sumo 19" SE HDR Monitor, Recorder, and Switcher
Choose PayGate at checkout for MobiCred Payments.
- 1920 x 1080 QLED Touchscreen Display
- HDMI 2.0 & 12G-SDI Inputs/Outputs
- Quad-HD Live Switching & 5-Ch Recording
- 1200 cd/m² Brightness
- ProRes RAW Support
- 10-Bit 422 ProRes/DNxHR Encoding
- HDR Mode with 10-Stop Dynamic Range
- Two XLR Inputs with +48V
Orms Bellville
Orms Cape Town
Remote Warehouse (Available in 2 - 4 Business Days)
Atomos Sumo 19" SE HDR Monitor, Recorder, and Switcher
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Remote Warehouse (Available in 2 - 4 Business Days)
Upper Canterbury Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- 1920 x 1080 QLED Touchscreen Display
- HDMI 2.0 & 12G-SDI Inputs/Outputs
- Quad-HD Live Switching & 5-Ch Recording
- 1200 cd/m² Brightness
- ProRes RAW Support
- 10-Bit 422 ProRes/DNxHR Encoding
- HDR Mode with 10-Stop Dynamic Range
- Two XLR Inputs with +48V
Choose PayGate at checkout for MobiCred Payments.
- 1920 x 1080 QLED Touchscreen Display
- HDMI 2.0 & 12G-SDI Inputs/Outputs
- Quad-HD Live Switching & 5-Ch Recording
- 1200 cd/m² Brightness
- ProRes RAW Support
- 10-Bit 422 ProRes/DNxHR Encoding
- HDR Mode with 10-Stop Dynamic Range
- Two XLR Inputs with +48V
The Atomos Sumo 19" SE HDR Monitor, Recorder, and Switcher maintains the same recording, monitoring and switching capabilities as its predecessor with a brighter 1200 cd/m‚² display brightness. As well as an upgraded 19" 1920 x 1920 QLED display.
Featuring 4 x 12G-SDI inputs and one HDMI 2.0 input that can receive video signals of up to 4K60 supporting live-quad channel switching.
Five-channel recording captures the input feeds and the live switching to create one output video for efficient viewing. Genlock and LTC timecode is also supported by the HDMI 2.0 and quad-SDI connections.
The Atomos Sumo 19" SE HDR Monitor, Recorder, and Switcher can record in ProRes RAW and 10-bit 422 ProRes/DNxHR encoding formats. RAW, Log, PQ, and HLG outputs from various sources are able to be processed by the device and mapped to display 10+ stops of dynamic range in real-time. The above makes the Sumo 19" SE perfect for monitoring in real-time.
SE Upgrades and Features
The Atomos Sumo 19" SE HDR features an upgraded 19" Quantum Dot OLED display with 1200 cd/m² brightness.
Live, Quad-channel HD switching and recording is possible. With the Atomos Sumo 19" SE HDR offers support in recording in ProRes RAW and 10-bit 422 ProRes/DNxHR.
Featuring support for HDMI 2.0 and quad-DSI support genlock and LTC timecode.
Live Quad-Channel HD Switching and Recording
Switching in real-time is possible by recording four streams simultaneously as separate ISO'swhile cueing. Switching is asynchronous and can be output with Atomos Connect 4K
HDR Capabilities
Featuring 10-bit processing taking RAW/Log/PQ/HLG output from compatible devices. The Atomos Sumo 19" SE HDR maps display 10+ stops of dynamic range.
Two XLR Inputs with Phantom Power
Featuring full-sized XLR connections with +48 phantom power. You are able to connect two external microphones for balanced analog audio recording and monitoring.
The Atomos Sumo 19" SE HDR features a dedicated meter, gain controls, and adjustments for frame delay on each channel.
Powering the SE
The Atomos Sumo 19" SE HDR offers dual 4-pin XLR inputs making it possible to power the unit continuously using battery power, an BattWing mounting bracket can be found for integration of a V-mount or Gold mount battery 95Wh or larger.
AC power supply is included with a 12-16.8V DC input.
- Atomos Sumo 19" SE HDR Monitor, Recorder, and Switcher
- Master Caddy II
- BattWing Mounting Bracket
- 4 x Screw
- 2 x Desktop Foot
- 4 x 1/4"-20 Mounting Screw
- AC Power Supply
Display
Panel Type | Quantum Dot OLED |
Display Size | 48.3 cm |
Resolution | 1920 x 1080 |
Aspect Ratio | 16:9 |
Touchscreen | Yes |
Maximum Brightness | 1200 cd/m2 |
Bit Depth / Color Support | 10-Bit (1.07 Billion Colors) |
HDR Compatibility | Hybrid Log Gamma |
Pixels Per Inch (ppi) | 120 ppi |
Real-Time LUT Monitoring | SDR, HDR |
Image Controls | Anamorphic De-Squeeze, False Color, Focus Peaking, OSD Flip, Pixel Zoom, RGB Parade, Vectorscope, Waveform, Zebra |
I/O
Video | 1 x HDMI Type A (HDMI 2.0) Input 1 x HDMI Type A (HDMI 2.0) Output 4 x BNC (12G-SDI) Input 1 x BNC (12G-SDI) Output |
Embedded Audio | HDMI: 8-Channel SDI: 12-Channel |
Audio | 2 x XLR Input 2 x XLR Output 1 x 3.5 mm Headphone Output |
Built-In Speaker | 2 x 5 W |
Power I/O | 2 x XLR 4-Pin (14.4 VDC) Input 1 x XLR 4-Pin (16.8 VDC) Input |
Other I/O | 1 x Genlock (BNC) Input 1 x LANC (2.5 mm) Input |
Media/Memory Card Slot | None |
File System Support | exFAT |
Format Support
Video Format | HDMI/SDI (10-Bit 4:2:2) UHD 4K: 60 DCI 4K: 60 |
Gamma Curve | DCI-P3, DCI-P3+, Panasonic V-Gamut, Rec709 |
Video Signal Conversion | HDMI to SDI SDI to HDMI |
Timecode Support | Yes |
Recording
Pulldown Conversion | 2:2, 3:2 |
Camera Trigger | SDI, HDMI |
Pre-Roll Record | Full HD: 8 Seconds 4K: 2 Seconds |
Encoding Formats | x ProRes Raw ProRes 422 HQ 10-Bit DNxHR 422 HQ 10-Bit |
Closed Caption Support | None |
Reference Input | None |
Phantom Power | +48 V |
Power
DC Input Power | 12 to 16.8 VDC |
Built-In Battery | None |
Battery Type | 2 x V-Mount, Gold Mount |
Power Consumption | 75 W |
Mounting
Mounting-Hole Pattern | 100 x 100 mm |
Mounting | 10 x 1/4"-20 Female 5 x 3/8"-16 Female |
Environmental
Operating Temperature | 40°C |
General
Material of Construction | Aluminum, Polycarbonate |
Dimensions | 504 x 330 x 180 mm, Including Feet 504 x 310 x 63 mm, Excluding Feet |
Weight | 5.45 kg |
