BlackMagic ATEM Camera Converter
Choose PayGate at checkout for MobiCred Payments.
- Enables Extension of SDI/HDMI Cameras
- Transmission Distance - 28 miles (45km)
- Internal Battery
- Talkback Function
- 12V Power Connection
- 2 Tally LEDs
- Integrated Belt Clip / Camera Mount
- Microphone Inputs
- Aircraft-grade Aluminum Construction
- Built-in Button Pad
Orms Bellville
Orms Cape Town
BlackMagic ATEM Camera Converter
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Enables Extension of SDI/HDMI Cameras
- Transmission Distance - 28 miles (45km)
- Internal Battery
- Talkback Function
- 12V Power Connection
- 2 Tally LEDs
- Integrated Belt Clip / Camera Mount
- Microphone Inputs
- Aircraft-grade Aluminum Construction
- Built-in Button Pad
Choose PayGate at checkout for MobiCred Payments.
- Enables Extension of SDI/HDMI Cameras
- Transmission Distance - 28 miles (45km)
- Internal Battery
- Talkback Function
- 12V Power Connection
- 2 Tally LEDs
- Integrated Belt Clip / Camera Mount
- Microphone Inputs
- Aircraft-grade Aluminum Construction
- Built-in Button Pad
Get everything you need for cameras in live production with a single converter! Connect your cameras SDI or HDMI outputs for conversion to optical fiber, while your switcher program feed can be fed back via optical fiber for camera monitoring. ATEM Camera Converter includes an internal battery, talkback, tally, and microphone inputs!
Get everything you need for cameras in live production with a single converter! Connect your camera’s SDI or HDMI outputs for conversion to optical fiber, while your switcher program feed can be fed back via optical fiber for camera monitoring. ATEM Camera Converter includes an internal battery, talkback, tally, and microphone inputs!
Features:
- Enables Extension of SDI/HDMI Cameras
- Transmission Distance - 28 miles (45km)
- Internal Battery
- Talkback Function
- 12V Power Connection
- 2 Tally LEDs
- Integrated Belt Clip / Camera Mount
- Microphone Inputs
- Aircraft-grade Aluminum Construction
- Built-in Button Pad
Introducing the world's most advanced broadcast grade production switchers! ATEM switchers include advanced technology and unique, powerful features, all built into a familiar M/E setup that's fast and easy to use. With an advanced broadcast SDI based design, ATEM also includes loads of HDMI connections for connecting low cost HDMI consumer cameras! Now you can get started with live production, the world's lowest cost and fastest way to produce professional video content!
Built to Perform
ATEM uses a familiar M/E style of operation so you get an instantly familiar workflow that's fast and easy to use. ATEM is affordably priced because you can start with the chassis only with software based control panel for Mac and Windows! If you then need a complete solution, simply add the ATEM 1 M/E or 2 M/E Broadcast Panel depending on your budget! The ATEM is a true broadcast grade panel with premium quality switches, faders and joysticks that are normally only found on the most expensive switchers available. ATEM even uses an FAA certified operating system for a true broadcast grade switcher!
Premium Quality
For the highest quality video with extremely low processing delay, ATEM features a fully digital 10-bit design. This means you get the highest quality available from cameras, servers and character generators with true 10-bit video quality maintained throughout the entire signal path. Get better chroma keying and seamless layering from HDMI and SDI sources so all your video maintains that pristine broadcast quality look. Even ATEM's built in analog video inputs and outputs feature low noise AD converters for incredible analog quality!
Creative Power
ATEM is the most creative solution for live switching! All transitions are instantly available with a button push on the control panel and include the same cut, mix and wipe found on traditional mixers! Plus you also get extra innovative ATEM transitions including dip, DVE, graphic wipe and stinger! It's simple to load clips into the 2 built in media players for exciting custom animated graphic transitions. ATEM features a built in DVE with 3D borders, light source and drop shadow! You can even use the DVE for transitions, or route into any of the 4 built in keyers for incredible multi-layer compositions!
Incredible Features
Only ATEM includes all these broadcast features at an affordable price! You get 4 upstream keyers, each with independent chroma, pattern, shaped and linear keying. You also get 2 downstream keyers and independent fade to black. Add unprecedented creativity with graphic wipes and stinger transitions using the 2 built in media players. For the ultimate in professional live production you can use the built in DVE for amazing DVE transitions or key repositioning! When you're on the move, the built in multi-view monitoring totally eliminates monitoring costs because all cameras, preview and program can be viewed on a single SDI or HDMI monitor! Nothing beats ATEM for creative features, quality and affordability!
Built in USB 3.0 Capture and Scopes!
With USB 3.0 becoming more popular on Windows computers, ATEM includes support for USB 3.0 capture direct to your PC! Get the most incredible quality 10-bit captures in full HD resolution for a direct file based master of your production. Because USB capture is connected to Aux 1, you can capture program or even clean feeds of your programming. ATEM includes our Media Express software for easy capture to AVI or DPX files. If you need high quality waveform monitoring, then ATEM also includes Blackmagic Design UltraScope software so you can use the USB connection for incredible PC based scopes!
New Software Control!
For the ultimate in portability, every ATEM production switcher includes beautifully designed control panel software for Mac and Windows, so you can even use your switcher from your laptop! ATEM software control provides a professional M/E workflow control panel with parameter adjustments in simple to use palettes. You can manage the switcher media pool and set all adjustments, and switcher control includes full keyboard shortcuts! Only ATEM lets you start at a lower cost because you’re not forced to buy a hardware control panel!
Great Range of Switchers
Choose an ATEM model for features you need and your budget! The ATEM 1 M/E model gives you 8 video inputs, 3 Aux outputs, SDI, HDMI and analog program outputs, SDI and HDMI multi view outputs, USB 3.0 as well as down converted SDI and composite outputs. Get the 2 M/E model for all these great features with SuperSource™, 16 inputs and 6 Aux outputs!
- Converter Utility
Video Input | SDI Video Input:1 x 10 bit SD/HD switchable SDI Video Output: 1 x 10 bit SD/HD switchable DMI Video Input: 1 x HDMI 1.3 type A connector HDMI Video Output: 1 x HDMI 1.3 type A connector Optical Fiber Video Input: 1 x 10 bit SD/HD switchable via LC connector Optical Fiber Video Output: 1 x 10 bit SD/HD switchable via LC connector |
Analog Audio | 2 x balanced 1/4" TRS connectors (stereo), line or microphone level in. When connected, replaces audio from SDI In or HDMI In. 1 x 3.5mm stereo connector for talkback microphone. 1 x 3.5mm stereo connector for stereo headphones (compatible with iPhone compatible headsets) |
Computer Interface | 1 x USB 2.0 high speed interface for configuration and firmware updates |
SDI Compliance | SMPTE 259M, SMPTE 292M |
Video Sampling | 4:2:2 |
Audio Sampling | Television standard sample rate of 48Khz, 24 bit A/D conversion |
Color Precision | 10 bit |
Color Space | 4:2:2 YUV |
Multiple Rate Support | SDI and HDMI switches between 270Mb/s SD-SDI and 1.5Gb/s HD-SDI |
Firmware Upgrade | Firmware built into software driver. Loaded at system startup or via updater software |
Power Supply | 12V power supply included with international socket adaptors for all countries |
Operating Systems Supported | Microsoft Windows XP, Windows Vista. Windows 7 and Apple Mac OS X |
