Blackmagic Design

Blackmagic Design 2110 IP Converter 4x12G PWR

R 43,195.00
R 43,195.00 R 43,195.00
Tax included. Shipping calculated at checkout.

BLA-CONVNVIPB4/12GPWR

Out of stock

Sorry, it's out of stock.

But we can let you know when it's back in.

SHORT DESCRIPTION

  • Converts Four 2110 IP Devices to 12G-SDI
  • Simultaneously Powers Devices
  • UHD 4K Resolution Support
  • One 12G-SDI Program Return Feed
  • Redundant Power

    The Blackmagic Design 2110 IP Converter 4x12G PWR is designed to bring your 12G-SDI broadcast gear up to SMPTE-2110 compliance standard. Providing bidirectional 12G-SDI to SMPTW-2110 video conversion connections.

    The Blackmagic Design 2110 IP Converter 4x12G PWR also supports up to four Studio 6K Pro Cameras via the 10G Ethernet connections with a 12G-SDI input for each connection. A PoE connection via each 10G Ethernet connection, it also supports providing power to the Studio cameras.

    The Blackmagic Design 2110 IP Converter 4x12G PWR features a 1 RU design that fits in a standard studio rack, as well as a 12G-SDI return input and redundant power.

    Main Features at a Glance

    • This converter is designed to add SMPTE-2110 IP video to 12G-SDI broadcast equipment
    • 1 RU design
    • Four independent bidirectional 12G-SDI to SMPTE-2110 IP video converters using RJ-45 10G Ethernet connections
    • It can supply high power to each 10G Ethernet connection guaranteed, so you can connect 4 Blackmagic Studio Camera 6K Pros, all at the same time
    • Each channel has a 12G-SDI input, and there's even a 12G-SDI program return input that sends to all channels

    Blackmagic Design 2110 IP Converter 4x12G PWR

    Inputs/Outputs
    Video I/O
    Input
    4x BNC (12G-SDI) Female
    1x BNC (12G-SDI) Female (Program)
    Output
    4x BNC (12G-SDI) Female
    1x BNC (12G-SDI) Female (Loop Output)
    Audio I/O
    Output
    1x 1/4" TRS Stereo Analogue Female
    Other I/O
    Input
    1x USB-C 3.0 / 3.1/3.2 Gen 1
    Input/Output
    4x RJ45 (10 GbE)
    Input/Output
    1x RJ45 (10/100/1000 Ethernet)
    Expansion Slots
    No
    Format Support
    Video Resolution
    BNC Input/Output
    4096 x 2160 at 24/25/29.97/30/47.95/48/50/59.94/60 fps
    3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
    1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
    1920 x 1080PsF at 25/29.97/30 fps
    1920 x 1080i at 50/59.94/60 fps
    1280 x 720 at 50/59.94/60 fps
    Embedded Audio
    LAN (RJ45)/SDI
    Standards
    Video Standard Compliance
    SMPTE: ST-2110
    HDCP Support
    No
    HDR Support
    Yes
    Hardware
    Wireless
    No
    OS Compatibility
    macOS 13 or Later
    Windows 10 to 11
    Display
    Display
    2.2" LCD
    Power
    Power I/O
    2x IEC C14 (100 to 240 VAC ) Input
    PoE Support
    PoE Proprietary
    General
    Operating Conditions
    5 to 40°C up to 90% Humidity
    Storage Conditions
    -20 to 45°C up to 90% Humidity
    Rack Form Factor
    1 U
    Dimensions
    48.3 x 23.42 x 4.42 cm
    Weight
    3.73 kg
