Blackmagic Design

Blackmagic Design 2110 IP Mini BiDirect 12G Converter

R 7,895.00
R 7,895.00 R 7,895.00
Tax included. Shipping calculated at checkout.

BLA-CONVNVIPF/IP/12G

Out of stock

Sorry, it's out of stock.

But we can let you know when it's back in.

SHORT DESCRIPTION

  • 12G-SDI to 2110 IP Converter
  • Video Monitoring To/From Studio Camera
  • Supports UHD 4K Video via SMPTE-2110 IP
  • 5-Pin XLR Talkback Control
  • Windows/macOS Software Utility
  • PoE and 10G Ethernet Power

    The Blackmagic Design 2110 IP Mini BiDirect 12G Converter enables you to connect your 12G-SDI broadcast studio camera to SMPTE-2110 IP systems. You will be able to send up to UHD 4K 12G-SDI camera video and program return signal with the same converter. Due to the compact form factor, you can easily mount the converter to your camera rig.

    On the Blackmagic Design 2110 IP Mini BiDirect 12G Converter you will find a 5-pin XLR talkback headset and a press-to-talk button which allows you to keep communication between camera operators and the broadcast booth.

    • This converter is bidirectional and allows 12G-SDI cameras to connect to SMPTE-2110 systems
    • Handles the SDI camera feed and SDI program return in the one converter
    • 5-pin XLR talkback headset connection with volume and press to talk buttons
    • Supports all SD, HD, and UHD standards up to 2160p60
    • Includes a 12 VDC power supply

    • Blackmagic Design 2110 IP Mini BiDirect 12G Converter
    • 12 VDC Power Supply

    Audio I/O
    Input
    1x XLR 5-Pin Analog Female
    Output
    1x XLR 5-Pin Analog Female
    Other I/O
    Input/Output
    1x RJ45 (10 GbE)
    Input
    1x USB-C (Firmware)
    1x USB-C (Device)
    Expansion Slots
    No
    Video Resolution
    BNC Input/Output (4:2:2)
    4096 x 2160 up to 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
    3840 x 2160 up to 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
    1920 x 1080p up to 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
    1920 x 1080PsF at 25/29.97/30 fps
    1920 x 1080i at 50/59.94/60 fps
    1280 x 720 at 50/59.94/60 fps
    Embedded Audio
    LAN (RJ45)/SDI
    Standards
    HDCP Support
    No
    Hardware
    Wireless
    No
    Power
    Power I/O
    1x Barrel (12 VDC ) Input
    PoE Support
    PoE++ 802.3bt
    General
    Operating Conditions
    5 to 40°C up to 90% Humidity
    Storage Conditions
    -20 to 45°C up to 90% Humidity
    Dimensions
    14.61 x 7.39 x 3.4 cm
    Weight
    295 g
