Blackmagic Design ATEM Television Studio HD8
Choose PayGate at checkout for MobiCred Payments.
- 8-Input 3G-SDI 1080p60 Live Switcher
- Redesigned Buttons and Layout
- Streaming Support, USB & M.2 Recording
- Blackmagic Cloud Integration
- Webcam Support, Runs Blackmagic OS
- Up to 16 Multiview Output Sources
- Audio Mixing, Transitions, T-Bar, AUX
- Customizable Electronic LCDs
- Studio Camera Control
- Timecode, MADI, Talkback
Orms Bellville
Orms Cape Town
Blackmagic Design ATEM Television Studio HD8
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- 8-Input 3G-SDI 1080p60 Live Switcher
- Redesigned Buttons and Layout
- Streaming Support, USB & M.2 Recording
- Blackmagic Cloud Integration
- Webcam Support, Runs Blackmagic OS
- Up to 16 Multiview Output Sources
- Audio Mixing, Transitions, T-Bar, AUX
- Customizable Electronic LCDs
- Studio Camera Control
- Timecode, MADI, Talkback
Choose PayGate at checkout for MobiCred Payments.
- 8-Input 3G-SDI 1080p60 Live Switcher
- Redesigned Buttons and Layout
- Streaming Support, USB & M.2 Recording
- Blackmagic Cloud Integration
- Webcam Support, Runs Blackmagic OS
- Up to 16 Multiview Output Sources
- Audio Mixing, Transitions, T-Bar, AUX
- Customizable Electronic LCDs
- Studio Camera Control
- Timecode, MADI, Talkback
The Blackmagic Design ATEM Television Studio HD8 enables you to add an all-in-one live streaming switcher to your production set-up, whether it is a remote production or in a live studio.
The Blackmagic Design ATEM Television Studio HD8 provides you with eight 3G-SDI inputs that support up to 1080p60 video, built-in live streaming, USB webcam support, a 58-channel audio mixer, chroma keyers, DVE, transitions, media players, internal recording, and talkback support. With this unit, you will have access to the BlackMagic Cloud, with the cloud you will have access to recordings from anywhere on earth.
Blackmagic Design ATEM Television Studio HD8
Available M/E Layers | 4 M/E |
Effect Types | 1 x DVE, Stinger 4 x Chroma Key 7 x Luma Key |
Downstream Keys | 2 x Chroma, Luma, DVE |
Generators | 7 x Pattern 2 x Color |
Audio Mixing | 58-Channel Mixing |
Processing | |
Switching Type | Pushbutton, Software, T-Bar |
Processing Resolution | 1080p at 60 |
Color Processing | 10-Bit 4:2:2 RGB |
Input | |
Number of Video Input Sources | 8 |
Video Inputs | 8 x BNC (3G-SDI) Female |
Input Video Format | SDI (10-Bit 4:2:2 RGB) 1080p at 23.98/24/25/29.97/30/50/60 fps 1080i at 50/59.94/60 fps 720p 50/59.94/60 fps |
Audio Inputs | 1 x BNC MADI Female 1 x 2RCA Stereo Analog Female 2 x XLR 3-Pin Analog Female 1 x XLR 5-Pin Female |
Embedded Audio Input | SDI |
Output | |
Video Output Channels | 8 |
Video Outputs | 8 x BNC |
Output Video Format | SDI (10-Bit 4:2:2 RGB) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps |
Audio Outputs | 2 x 1/4" TRS Stereo Analog Female |
Embedded Audio Output | SDI |
Multiview Output | 16-Way Multiview |
Monitor Output | 1 x HDMI |
Connectivity | |
Other I/O | 1 x BNC Reference Input 1 x BNC Reference Output 1 x BNC Timecode 1 x BNC Timecode 4 x RJ45 LAN Input/Output 1 x RJ45 Talkback Input/Output 1 x RJ12 Remote Input/Output 2 x USB-C Output |
Video Standard Compliance | SMPTE 292M/296M/424M/425M-A/425M-B |
IP Video | H.264: 1920 x 1080 at 60p Encoding |
Transport Protocols | RTMP, TCP/IP |
Hardware | |
OS Compatibility | macOS 12 to 13 or Later Windows 10 to 11 *As of February, 2023: Check with manufacturer for the most up-to-date compatibility |
Wi-Fi | None |
Bluetooth | None |
Power I/O | 1 x IEC C14 (100 to 240 VAC) Input 1 x XLR 4-Pin (12 VDC) Input |
Power Consumption | Device: 100 W |
Environmental | |
Operating Temperature | 0 to 40°C |
Storage Temperature | -20 to 60°C |
Operating Humidity | 0 to 90% |
Storage Humidity | 0 to 90% |
General | |
Weight | 6.8 kg |
