Blackmagic Design HyperDeck Extreme 4K HDR
Choose PayGate at checkout for MobiCred Payments.
- Large LCD with Touchscreen Deck Controls
- Physical Controls, Two CFast Card Slots
- 12G-SDI, HDMI, and Legacy Analog
- Fast USB Type-C Disk Port; 10G Ethernet
- PCIe Cache Card Slot
- H.265 Recording/Playback, ProRes Support
- Rec. 2020/709 Support, HDR Scopes
- SDI/HDMI Auto HDR Detection
- Multichannel SDI and Analog Audio
- Load and Save 3D LUTs
Orms Bellville
Orms Cape Town
Blackmagic Design HyperDeck Extreme 4K HDR
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Large LCD with Touchscreen Deck Controls
- Physical Controls, Two CFast Card Slots
- 12G-SDI, HDMI, and Legacy Analog
- Fast USB Type-C Disk Port; 10G Ethernet
- PCIe Cache Card Slot
- H.265 Recording/Playback, ProRes Support
- Rec. 2020/709 Support, HDR Scopes
- SDI/HDMI Auto HDR Detection
- Multichannel SDI and Analog Audio
- Load and Save 3D LUTs
Choose PayGate at checkout for MobiCred Payments.
- Large LCD with Touchscreen Deck Controls
- Physical Controls, Two CFast Card Slots
- 12G-SDI, HDMI, and Legacy Analog
- Fast USB Type-C Disk Port; 10G Ethernet
- PCIe Cache Card Slot
- H.265 Recording/Playback, ProRes Support
- Rec. 2020/709 Support, HDR Scopes
- SDI/HDMI Auto HDR Detection
- Multichannel SDI and Analog Audio
- Load and Save 3D LUTs
The Blackmagic Design HyperDeck Extreme 4K HDR is designed as a playback and recording deck for your broadcast studio, live production, or digital signature environment. Supporting up to UHD 4K video as well as allowing you to save H.265 files and utilize 3D Luts, internal cache, as well as HDR support for video playback.
You will find a 7" touchscreen LCD screen that provides a clean image and controls, scopes, and monitoring tools that you can control and configure with a swipe or a button press. Featuring 12G-SDI and HDMI inputs and outputs, with two CFast media slots for recording. The Blackmagic Design HyperDeck Extreme 4K HDR also allows you to record video streams to an optional disk via USB Type-C.
The Blackmagic Design HyperDeck Extreme 4K HDR can fit into your legacy production rack, being controlled via RS-422 as traditional broadcast decks. Featuring a 3G-SDI monitor output, component analog audio and video inputs, 3-pin XLR inputs and outputs, timecode I/O, and reference I/O.
Updated HyperDeck
The Blackmagic Design HyperDeck Extreme 4K HDR features innovations such as space-saving H.265 files, optional internal cache, 3D LUTs, and HDR support. It also features the ability to record up to native 4K in H.265, this provides you with a good image quality taking up very little disk space. A large 7" LCD touchscreen ensures a perfect view of your recording as well as control over all deck settings.
File and I/O Formats
Powerful Ultra HD touchscreen HyperDeck records and plays H.265 and ProRes files in all SD, HD, and Ultra HD standards up to 2160p60. It includes scopes and an upgradable cache, plus SDI, HDMI, and analog video.
Interfaces and Inputs
Featuring a large 7" touchscreen with the user interface as well as deck controls, as well as a large screen to view your recording. Furthermore, it features two media slots, 12G-SDI I/O, HDMI I/O analog connections for archiving, USB Type-C external disk recording, plus a front panel speaker and headphone jack for live monitoring.
Live Production, Signage, and Archiving
The Blackmagic Design HyperDeck Extreme 4K HDR offers exceptional versatility and is perfect for live streaming as a master recorder, clip player, and for recording ISO cameras. With the analog inputs you are allowed to record from old video types, this enables you to use the latest streaming services or editing.
Convert Legacy Programming for Streaming
You are able to connect to legacy broadcast decks, set an in and an out point, and then edit. Just add HyperDeck Extreme and HyperDeck Extreme Control to each legacy deck to keep them all archiving constantly with just one operator. It's even possible to edit across formats by using Teranex Express to convert tapes from SD to HD in one step. You can control a wide range of decks, including Digital Betacam, 1" C format, and Betacam SP.
Dual CFast Media
The Blackmagic Design HyperDeck Extreme 4K HDR enables you to record to commonly available flash memory cards. The recorded H.265 files are small enough to be able to record longer recordings to a standard CFast card. Because of the dual slots for CFast cards you are able to hot swap cards to enable infinite recording lengths.
12G-SDI, HDMI, and Legacy Analog
Multi-rate 12G-SDI for SD, HD, and Ultra HD 4K connections are available as video connections. FTP protocols are available for high-speed upload using the latest 10G Ethernet.
HDR Support and Bright Wide Gamut LCD
The Blackmagic Design HyperDeck Extreme 4K HDR supports the latest HDR standards with a bright touchscreen with a wide colour ganut.
Compatible with Controllers, Switchers, Converters
The Blackmagic Design HyperDeck Extreme 4K HDR features compatibility with a wide variety of other BlackMagic products, including the BlackMagic HyperDeck Extreme Control, enabling adding traditional broadcast deck controls. It uses an RS-422 deck control protocol, this enables you to use any broadcast deck. Add the Blackmagic MultiDock 10G to use regular SSDs for compatibility with media from other HyperDeck models. For monitoring, the Teranex SDI to HDMI 8K allows broadcast monitoring on television, and it also has monitor calibration, 3D LUTs, and on-screen scopes.
Blackmagic Design HyperDeck Extreme 4K HDR
General
Compatibility | Blackmagic Design ATEM Mini |
Video Formats | DCI 4K: 25, 24, 23.98 UHD 4K: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 DCI 2K: 25, 24, 23.98 DCI 2K PsF: 25, 24, 23.98 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 1080i: 60, 59.94, 50 720p: 60, 59.94, 50 525i: 59.94 625i: 50 |
Display | 7" Capacitive Touchscreen HDR LCD |
Resolution | 1920 x 1200 |
Video Sampling | 10-Bit, 4:2:2 YUV |
Colour Space | Rec 601, Rec 709, Rec 2020 |
SMPTE Standards | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10, and SMPTE 2084 |
Supported Codecs | ProRes HQ QuickTime ProRes 422 QuickTime ProRes LT QuickTime up to 2160p60 ProRes 4444 (Playback Only) H.265 High H.265 Medium H.265 Low up to 2160p60 |
Compatible Operating Systems | Mac 11.1 Big Sur Mac 12.0 Monterey or Later Windows 10 and 11 |
Inputs/Outputs
USB I/O | 1 x USB Type-C (USB 3.1 / 3.2 Gen 1) Female Output |
Video I/O | 1 x BNC (12G-SDI) Input 2 x BNC (12G-SDI) Output 1 x BNC (Component) Input 1 x HDMI Type A (HDMI 2.0) Input 1 x HDMI Type A (HDMI 2.0) Output 1 x BNC (3G-SDI) Monitor Output 1 x USB Type-C Output |
Audio I/O | 4 x XLR 3-Pin Input 4 x XLR 3-Pin Output 1 x 2RCA Input |
Other I/O | 1 x 9-Pin DSub, RS-422 Input 1 x 9-Pin DSub, RS-422 Output 1 x 3-Pin XLR, Timecode Input 1 x 3-Pin XLR, Timecode Output 1 x BNC, Reference Input 1 x BNC, Reference Output 1 x RJ45 Ethernet 1 x USB Type-C Input |
Power
Power Source | AC Input (Built-In) |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
DC Input Power | 12 VDC |
Power Consumption | 190 W |
Environmental
Operating Temperature | 0 to 40°C |
Operating Humidity | 0 to 90% (Non-Condensing) |
Storage Temperature | -20 to 60°C |
Storage Humidity | 0 to 90% (Non-Condensing) |
Physical
Dimensions | 33.4 x 21.03 x 13.06 cm |
Weight | 225 g |
