Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom
Choose PayGate at checkout for MobiCred Payments.
- Capture up to UHD 4K30 / 1080p60 Video
- 8.29MP 1/2.3" CMOS Sensor with Hybrid AF
- HDMI, 6G-SDI & IP/NDI Video Output
- IP65-Rated Dust/Water-Resistant Housing
- 20x Optical, 20x Digital Zoom, AWB
- PoE++ Support, AC Adapter Included
- Canon DIG!C DV6 Chip, Built-In Wiper
- IP & RS-422 Serial Control
- VISCA Serial/Canon XC IP Protocols
- Compatible with Canon PTZ Controller
Orms Bellville
Orms Cape Town
Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom
Orms Bellville
Ground Floor, Tygervalley Chambers 2, 27 Willie Van Schoor Avenue
Bellville
Bellville
Western Cape
7530
South Africa
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- Capture up to UHD 4K30 / 1080p60 Video
- 8.29MP 1/2.3" CMOS Sensor with Hybrid AF
- HDMI, 6G-SDI & IP/NDI Video Output
- IP65-Rated Dust/Water-Resistant Housing
- 20x Optical, 20x Digital Zoom, AWB
- PoE++ Support, AC Adapter Included
- Canon DIG!C DV6 Chip, Built-In Wiper
- IP & RS-422 Serial Control
- VISCA Serial/Canon XC IP Protocols
- Compatible with Canon PTZ Controller
Choose PayGate at checkout for MobiCred Payments.
- Capture up to UHD 4K30 / 1080p60 Video
- 8.29MP 1/2.3" CMOS Sensor with Hybrid AF
- HDMI, 6G-SDI & IP/NDI Video Output
- IP65-Rated Dust/Water-Resistant Housing
- 20x Optical, 20x Digital Zoom, AWB
- PoE++ Support, AC Adapter Included
- Canon DIG!C DV6 Chip, Built-In Wiper
- IP & RS-422 Serial Control
- VISCA Serial/Canon XC IP Protocols
- Compatible with Canon PTZ Controller
The Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom is the perfect solution for you if you need a professional remote camera for outdoor environments that needs minimal crew to operate. Perfect for your house of worship, corporate conference room, government application, courtroom, broadcast streaming production, event space, or even add an extra camera to your documentary shoot.
The weather resistant exterior features a durable aluminium body with a IP65 waterproof rating, interior fan, even a built-in wiper for the lens.
The Canon CR-X300 sports many features of a Canon camcorder such as a 1/2.3" dual-pixel CMOS sensor, Hybrid AF, the Canon DIG!C DV6 image processor, scene modes, IR (infrared) mode, 20x optical zoom, 20x digital zoom, built-in waterproof microphone, and video capture and output up to UHD 4K. The camera also includes NDI|HX support without requiring a separate license, allowing you to drop the camera into your existing NDI network with minimal configuration.
This camera can be controlled via IP and RS-422 serial as well as HDMI, 6G-SDI, and IP streaming outputs, it is also compatible with the Canon RC-IP100 Touchscreen PTZ Joystick Controller. With these you are able to perform smooth pan, tilt, and zoom functions with a range of 0.3 to 60° per second from a remote location. The camera can also be powered using PoE++ (Power-over-Ethernet) using its LAN port, so it can fit right into your existing PoE+ network without requiring the use of local power to save cabling.
Key Features
Advanced 4K UHD CMOS Image Sensor
The Canon CR X300 features 1/2.3-inch, approximately effective 8.29MP UHD 4K CMOS Pro Image Sensor that captures 3840 x 2160 pixels.With the high sensitivity sensor employed in the SR-X300 vivid, and accurate video is produced with an outstanding signal-to-noise ratio.
DIG!C DV 6 Image Processor
The DIG!C DV 6 Image Processor provides improved picture quality for both UHD 4K video and Full HD with oversampled HD processing.
4K29.97 and 1080p59.94 4:2:2 10-Bit Output
Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom features 6G-SDI and HDMI outputs for uncompressed signals at 840 x 2160 or 1920 x 1080 resolution with 4:2:2 color sampling and 10-bit color depth.
Hybrid AF
Equipped with Hybrid AF. That combines contrast AF technology with high-speed phase-difference auto-focus technology.
The Face Detection and Tracking functions which detects faces and automatically adjusts focus when a human is detected.
Advanced Full HD Image Quality
The Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom features Full HD image quality all thanks to oversampling HD processing, this enables Full HD by utilizing the outstanding capabilities of the UHD 4K CMOS sensor.
Four Scene Modes for Impressive Video
- Portrait Mode: provides a blurred background with the subjects in perfect focus.
- Sports Mode: enhances capture of moving subjects
- Low Light: allows for capture of bright images in dark areas
- Spotlight Mode: enhances capture of beautiful images of spotlighted objects.
IR Mode
In little to no ambient light, the CR-X300 features and Infrared Mode. The IR Mode removes the infrared filter from the optical path.
Outdoor Features
IR65 Rating
This PTZ Camera features an waterproof and dustproof construction with a IP65 enclosure making the unit perfect for outdoor use and in inclement weather conditions.
Built-In Wiper
The Canon CR-X300 Outdoor 4K PTZ Camera features are equipped with and enhanced servo 1/32 ND filter as well as wiper unit. The CR-X300 is also equipped with a fan for heat dissipation, which helps to ensure the camera continues operation without issue.
Canon UHD 4K Lens
20x Zoom Range
The Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom features a versatile zoom range with 35mm equivalent of 29.3 to 601mm.
An 65.5° angle of view is achieved when the unit is set to UHD 4K and 63.5° angle of view when set in full HD.
20x Digital Zoom
An super-telephoto zoom can be achieved with a maximum 400x zoom. This is achieved by Optical 20x + Digital 20x.
Image Stabilization Options with Two Types of IS Modes
In addition to the Standard optical IS mode, CR-X300 is also equipped with the powered IS mode that compensates for blurring during telephoto shooting.
ND Filters
Remote internal exposure control is allowed using internal ND filtration up to 1/8.
For more demanding applications, there will be 1/32 filter that can be manually activated.
Smooth & Responsive Pan and Tilt Performance
The Canon CRX 300 features a strong pan and tilt mechanism allowing for a range of ±180° pan, -40° to +215° tilt, allowing for outstanding movement flexibility, whether mounted in a standard manner, or inverted.
With variable pan and tilt speeds from 0.3° to 60°/per second.
Various Interfaces Supported for Multiple Environments
6G-SDI and HDMI Outputs
The CR-X300 features industry-standard 6G-SDI and HDMI video outputs for easy integration into professional video environments. With these interfaces, the user can achieve of output of up to 4K UHD at 29.97p or Full HD at up to 59.94p. Furthermore, the CR-X300 is equipped with a built-in weatherproof microphone that can be utilized to capture audio.
PoE++ Single Cable Solution
The Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom features PoE++ support, which allows for a single-cable installations. The allows for any combination of power, control, and video feed over an standard IP connection.
Easy Integration into IP Streaming
IP Multi-Stream Support
The CR-X300 can simultaneously distribute video to multiple protocols via IP. Simultaneous distribution is also known as multi-stream, and the CR-X300 can distribute a total of three video streams simultaneously.
RTMP Streaming Protocol Supported
This PTZ camera also allows for live streaming for popular platforms including Facebook Live, YouTube, Twitch, and others.
NDI|HX Live Video Production Support Protocol
Supporting the NDI|HX (Network Device Interface) protocol that is well-established in the field of video production and broadcasting as the supporting RTP (Real-time Transport Protocol).
Standard (VISCA) Protocol
It is possible to control the Canon CR-X300 Outdoor 4K PTZ Camera via IP by supporting of Standard (VISCA) Protocol. The VISCA protocol with the CR-X300 is considered as an industry standard and easily integrates with existing workflows.
Versatile Integration
BT.709 and BT.2020 Colour Spaces
This PTZ camera employs BT.709 and BT.2020 Colour Spaces similar to other Canon high end cinema cameras including the XF705, XF605 and Cinema EOS System. This makes integration easy into a multi camera system.
Genlock
You have the option to sync your Canon CR-X300 with other units in multi-camera environments using Genlock with which this camera is equipped.
Multiple Control Protocols
The CR-X300 can be controlled via a large variety of protocols, including XC (Canon's original), NU (Canon's original), RTSP/RTP, NDI|HX, RTMP/RTMPS, Standard Communication over serial (VISCA Serial), and Standard Communication over IP (VISCA IP).
Hardware or Software Remote Camera Control
The Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom offers support for a variety of protocols. The controller have a variety of controller choices, these include both hardware and software options. These include, the Canon RC-IP100 Touchscreen PTZ Joystick Controller (not included) herewith the controller have the option of controlling up to 100 cameras as well as 100 presets per camera.
Canon's Remote Camera Control Application can also be used to control the CR-X300 on a software basis offering "multi-camera operation".
- Canon CR-X300 Outdoor 4K PTZ Camera with 20x Zoom (Titanium White)
- Connector Cover
- Power Cable
Sensor Type | 1/2.3"-Type CMOS Sensor |
Sensor Resolution | Actual: 21.14 Megapixel Effective: 8.29 Megapixel (3840 x 2160) |
IR Cut Filter | Yes |
Built-In ND Filter | Mechanical Filter Wheel with 3-Stop (1/8), 5-Stop (1/32) ND Filters |
Image Stabilization | Optical in Integrated Lens |
Focus Control | Autofocus Manual Focus |
Shutter Type | Electronic Rolling Shutter |
Shutter Speed | 1/2000 to 1/6 Second |
Gain | 0 to 36 dB |
Precise Scan Rate Control | No |
Minimum Illumination | 3 Lux at 1/60 Shutter Speed |
Flip / Mirror Support | Image Flip |
White Balance | 2000 to 15,000K Presets: AWB, Manual, Set A, Set B |
Focal Length | 3.7 to 73.4mm (35mm Equivalent Focal Length: 30.5 to 627mm) |
Optical Zoom Ratio | 20x |
Max Digital Zoom | 20x |
Field of View | Horizontal: 65.6 to 3.6° Vertical: 39.8 to 2° |
Maximum Aperture | f/1.8 to 2.8 |
Minimum Focus Distance | Wide: 1.0 cm Telephoto: 60.0 cm |
External Recording Modes | 4:2:2 10-Bit via HDMI 3840 x 2160 at 23.98/25/29.97 fps 1920 x 1080p at 23.98/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps 1280 x 720 at 50/59.94 fps 4:2:2 10-Bit via SDI/BNC 1920 x 1080p at 23.98/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps 1280 x 720 at 50/59.94 fps 4:2:0 8-Bit via RJ45 3840 x 2160 at 5/6/12/12.50/15/23.98/25/29.97 fps 1920 x 1080p at 5/6/12/12.50/15/23.98/25/29.97/50/59.94 fps 1280 x 720 at 5/6/12/12.50/15/23.98/25/29.97/50/59.94 fps 640 x 360 at 5/6/12/12.50/15/23.98/25/29.97/50/59.94 fps |
Embedded Audio | SDI |
Broadcast Output | NTSC/PAL |
Gamma Curve | Rec709, Rec2020 |
IP Streaming | NDI|HX, RTMP, RTMPS, RTP, RTSP 3840 x 2160 1920 x 1080 1280 x 720 640 x 360 |
Presets | 100 via IP, VISCA |
Move Speed | Pan: 0.3 to 60°/sec Tilt: 0.3 to 60°/sec |
Movement Range | Pan: 360° (-180 to 180°) Tilt: 130° (-40 to 215°) |
Tally Light | Yes |
Supported Control Protocols | Canon XC IP RS-422 VISCA |
Video I/O | 1 x BNC (6G-SDI) Output 1 x HDMI Output 1 x RJ45 (NDI) Output |
Other I/O | 1 x BNC (Genlock) Input 1 x RJ45 (RS-422, VISCA) Input |
Built-In Microphone Type | Stereo |
Built-In Speaker | No |
PoE Support | PoE++ 802.3bt |
Power I/O | 1 x Barrel (12VDC) Input |
Power Consumption | PoE: 40 W Power Supply: 12 VDC 40 W |
Operating Temperature | -15 to 40°C |
Operating Humidity | 0 to 90% (Non-Condensing) |
Material of Construction | Aluminum |
IP Rating | IP65 |
Environmental Protection | Advertised as Weather Resistant *Manufacturer Testing: IP65 |
OS Compatibility | Windows 10 (64-Bit Only) macOS 11 |
Mobile App Compatible | Yes: Android & iOS Functionality: Adjust Settings |
Sound Level | NC45 (at Full Speed) |
Dimensions (W x H x D) | 31.09 x 21.69 x 21.69 cm 21.69 x 31.09 x 21.69 cm |
Weight | 7 kg |
