The Canon EOS R5 C Mirrorless is a full frame mirrorless cinema camera that offers both photographer and videographers complete professionalism as it combines the worlds of Cinema EOS and EOS R into one, which sits below the EOS C70 in the Cinema range and alongside the EOS R5.
Built-in to the Canon R5C mirrorless camera is an incredible 45MP CMOS Image Sensor and a powerful DIGIC X Image Processor to ensure that remarkable image quality can be delivered each and every time when capturing at 20 fps. The camera is the smallest and most versatile Cinema EOS camera that will ensure outstanding 8K cinematic full-frame video in 4:2:0 10-bit; fast, accurate, reliable focusing; extensive professional recording formats and tools, a great selection of advanced connectivity, and it features a lightweight design with an active cooling system to enable extended time on 8K video recording up to 60 fps.
Advanced 45MP Full-Frame CMOS Sensor
Powered into this advanced Canon EOS R5C Mirrorless Camera is an advanced 45MP CMOS Image Sensor. The image sensor ensures superior image quality, raising the bar in high level stills and video recording - leaving you with great sharpness, clarity, tonal gradation and dynamic range in image and outstanding video quality.
Powerful DIGIC X Image Processor
The Canon EOS R5C is equipped with its most advanced and latest image processor, the DIGIC X. The powerful DIGIC X Image Processor ensures that a wide range of high-end functions can be made possible such as 8K video recording up to 60 fps, an ISO sensitivity of 100-51200 (in 1/3-stop or 1 stop increments) and it can be expanded to a high of 102400 and still keeping digital noise to a minimum; superior image quality with outstanding sharpness and clarity; blistering autofocusing speeds and more.
8K Sensor and DIGIC X Processor
The Canon R5C Cinema camera is the first to provides internal 8K (8192x4320) 60P RAW video recording. Recording in 8K quality will ensure that outstanding definition and realism with 16 times the resolution of Full HD video is produced, which will enable unprecedented capabilities in video expression and high flexible workflows for professionals, such as 4K cropping from 8K video footage. Additionally, it can also record 8K video in the highly versatile MP4 format, as well lighter and small proxy video files while recording 8K video.
Video Control for the Dedicated Video Professional
Videographers can enjoy the Canon EOS R5 C even more now as it's packed with professional functionality to get the job done. As soon as the main switch is moved to the video position, it immediately switches over to the Cinema EOS menu system and interface. The advance menu will provide high-level video features such as waveform monitors, video codec options, and extensive audio control which is ideal for the experienced camera operator or video content creator.
Supports 8K/60 Internal RAW Recording
With the advanced 8K sensor and DIGIC X Image processor built-in, the Canon EOS R5 C Cinema Camera is capable of producing high-quality video at up to 8K/60. When using the Cinema RAW Light format with it's high-efficiency mode, it will enable internal card recording witout an external recorder.
Internal Cooling Fan to Enable Non-Stop 8K/60 Recording
With the built-in Cooling Fan, the Canon EOS R5 C Mirrorless Cinema Camera will be able to force out the heat from inside. This also enables continuous and virtually limitless shooting of high-definition 8K/60 video without any interruptions occurring.
Expanded Interface for Professional Needs
With an expanded interface, the Canon R5 C camera provides a Timecode input/output terminal for easy synchronization when recording with multiple cameras and other interfaces. Included is a cable protector to ensure that the cable doesn't get disconnected or that it doesn't damage the terminal if any strong force is applied when connecting interface or HDMI cables.
The multi-functional shoe with audio interface ensures users that it will be able to support the optional TASCAM CA-XLR2d-C professional audio XLR microphone adapter for up to 4-channel audio.
Carries on the Ergonomic EOS Design
The Canon EOS R5 C camer body is incredibly compact and lightweight, making it easy for videographers especially to operate. When pairing a Canon RF lens or an EF lens via the EF-EOS R mount adapter, the camera is guaranteed to produce outstanding performance that fits easily and comfortably in your hand and making it a complete breeze. The Electronic Viewfinder is optically extended, for eye-level viewing which is similar to the conventional EOS R5 camera and it used the same ergonomic grip design.
High-Speed Continuous Shooting @ 20fps
Go out and capture just about everything, whether it be fast moving subjects, the Canon EOS R5 C Camera will perform exceptionally well by capturing them. The camera allows a continuous shooting speed of up to 12 fps with mechanical shutter and up to 20 fps with silent shutter, and at the same time still retaining sharpness and remarkable image quality.
Intelligent Autofocus System & Subject Detection
Canon has incorporated its Dual Pixel CMOS AF II Technology with 5940 areas & total coverage into this sophisticated camera. The Dual Pixel CMOS AF II adopts really high-speed autofocus calculations to match its powerful high-speed shooting capability of up to 20fps. It also ensures an AF System that covers 100% horizontally and 100% vertically with Face + Tracking and Auto Selection modes.
With blistering autofocus speeds, the Canon EOS R5 C camera can focus in as little as 0.05 seconds - definitely being a step-change in performance, and the camera is also functional in light levels as low as -6EV.
Dual Memory Card Slots
You'll never have to worry with storage space getting any less as the Canon EOS R5 C camera's design incorporates a dual memory card slot that's capable of reading a high-speed CFexpress card as well as a UHS- II SD card.
Built-in 0.5" 5.76-Million Dots OLED EVF with 120fps Refresh Rate Vari-Angle Touchscreen
Powered into this Canon EOS R5C Mirrorless Camera is a bright and high-precision 0.5" 5.76-Million Dots OLED EVF with a 120fps Refresh Rate Vari-Angle Touchscreen with a 23mm eyepoint. The OLED EVF provides photographers with a bright image and extensive shooting information; it supports a 120 fps refresh rate, and it also provides a sharp and colourful 100% view of the subject at hand with minimal aberration or distortion.
- Canon EOS R5 C Mirrorless Camera Body
- Canon LP-E6NH Battery
- Canon LC-E6 Battery Charger
- Shoulder Strap
- USB-C Cable
- Cable Protector
- AC Cable
- User Manual Kit
Imaging
| Lens Mount | Canon RF |
| Lens Communication | Yes, with Autofocus Support |
| Sensor Resolution | Actual: 47.1 Megapixel Effective: 45 Megapixel (8192 x 5464) |
| Sensor Type | 36 x 24 mm (Full-Frame) CMOS |
| Crop Factor | 1.6x |
| Image Stabilization | Sensor-Shift (Video Only) |
| Built-In ND Filter | None |
| Internal Filter Holder | No |
| Capture Type | Stills & Video |
Exposure Control
| Shutter Type | Electronic Shutter, Focal Plane Shutter |
| Shutter Speed | Mechanical Shutter 1/8000 to 30Â Seconds Electronic Front Curtain Shutter 1/8000 to 30Â Seconds Electronic Shutter 1/8000 to 0.5Â Seconds |
| Bulb/Time Mode | Bulb Mode |
| ISO Sensitivity | Photo: 100 to 51,200 in Manual Mode (Extended: 50 to 102,400) Photo: 100 to 25,600 in Auto Mode (Extended: 200 to 51,200) |
| Metering Method | Centre-Weighted Average, Evaluative, Partial, Spot |
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
| Exposure Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Metering Range | -3 to 20 EV |
| Continuous Shooting | Mechanical Shutter Up to 12 fps at 45 MP for up to 180 Frames (Raw) / 350 Frames (JPEG) Electronic Shutter Up to 20 fps at 45 MP for up to 83 Frames (Raw) / 170 Frames (JPEG) |
| Interval Recording | Yes |
| Self-Timer | 2/10-Second Delay |
Internal Video Capture
| Raw Recording | Cinema RAW Light 8192 x 5464 at 24.00/25/50 fps [1030 to 2570 Mb/s] 5952 x 3140 at 30/50 fps [544 to 1360 Mb/s] 2976 x 1570 at 25/29.97/30/50 fps [138 to 344 Mb/s] |
| Recording Modes | Raw 12-Bit DCI 8K (8192 x 4320) at 25p [2600 Mb/s] AVC-Intra/AVC-LongG/XF-AVC 4:2:2 10-Bit DCI 4K (4096 x 2160) at 25p/100p [160 to 810 Mb/s] UHD 4K (3840 x 2160) at 25p/50p/100p [160 to 810 Mb/s] Full HD (1920 x 1080) at 25p/50p [50 to 310 Mb/s] HD (1280 x 720) at 50p [8 to 12 Mb/s] AVC-LongG/MP4 4:2:2 10-Bit DCI 8K (8192 x 4320) at 25p [400 to 540 Mb/s] UHD 8K (7680 x 4320) at 25p [400 to 540 Mb/s] DCI 4K (4096 x 2160) at 25p/50p/100p [100 to 225 Mb/s] UHD 4K (3840 x 2160) at 25p/50p [100 to 225 Mb/s] DCI 2K (2048 x 1080) at 25p/50p [35 to 50 Mb/s] Full HD (1920 x 1080) at 25p/50p [35 to 50 Mb/s] HD (1280 x 720) at 50p [8 to 12 Mb/s] AVC-LongG/MP4 4:2:0 8-Bit DCI 4K (4096 x 2160) at 25p/50p [100 to 225 Mb/s] UHD 4K (3840 x 2160) at 25p/50p [100 to 225 Mb/s] DCI 2K (2048 x 1080) at 25p/50p [35 to 50 Mb/s] Full HD (1920 x 1080) at /50p [35 to 50 Mb/s] HD (1280 x 720) at 50p [8 to 12 Mb/s] |
| Sensor Crop Modes | Super35 / APS-C 5952 x 3184 4096 x 2160 3840 x 2160 Super16 2976 x 1570 |
| Gamma Curve | Canon Log 3, HDR-HLG, HDR-PQ, Rec2020, Rec709 |
| Recording Limit | Unlimited |
| Video System | PAL |
External Video Capture
| External Recording Modes | 4:2:2 10-Bit via HDMI DCI 4K (4096 x 2160) up to 59.94p UHD 4K (3840 x 2160) up to 59.94p |
Still Image Capture
| Image Sizes | 3:2 Raw 8192 x 5464 5088 x 3392 3:2 8192 x 5464 5808 x 3872 4176 x 2784 2400 x 1600 4:3 7280 x 5464 5152 x 3872 3715 x 2784 2112 x 1600 16:9 8192 x 4608 5808 x 3264 4176 x 2344 2400 x 1344 1:1 5456 x 5456 3872 x 3872 2784 x 2784 1600 x 1600 |
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
| Image File Format | JPEG, Raw, HEIF |
| Bit Depth | 10-Bit |
Interface
| Media/Memory Card Slot | Slot 1: CFexpress Type B Slot 2: SD/SDHC/SDXC (UHS-II) |
| Video I/O | 1 x Micro-HDMI Output |
| Audio I/O | 1 x 3.5 mm TRS Stereo Mic/Line Input 1 x 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1 x USB Type-C (9 VDC at3 A) Input |
| Other I/O | 1 x USB Type-C USB 3.2 / 3.1 Gen 2 (Shared with Power Adapter) |
| Wireless | Bluetooth Control 2.4 / 5 GHz Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g), Wi-Fi Video Output, Control |
Monitor
| Size | 3.2" |
| Resolution | 2,100,000 Dot |
| Display Type | Free-Angle Tilting Touchscreen LCD |
Viewfinder
| Type | Built-In Electronic (OLED) |
| Size | 0.5" |
| Resolution | 5,790,000 Dot |
| EyePoint | 23 mm |
| Coverage | 100% |
| Magnification | Approx. 0.76x |
| Diopter Adjustment | -4 to +2 |
Focus
| Focus Type | Auto and Manual Focus |
| Focus Mode | Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S) |
| Autofocus Points | Phase Detection: 1053 |
| Autofocus Sensitivity | -6 to +20 EV |
| Built-In Flash | No |
| Maximum Sync Speed | 1/250 Second |
| Flash Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Dedicated Flash System | eTTL |
| External Flash Connection | Hot Shoe |
Environmental
| Operating Temperature | 0 to 40°C |
| Operating Humidity | 0 to 85% |
| Battery Type | Canon LP-E6N |
| Accessory Mount | 1 x Intelligent Hot Shoe |
| Dimensions (W x H x D) | 142.2 x 101.6 x 111.8 mm |
| Weight | 680 g (Body Only) 770 g (With Battery, Recording Media) |
