Atomos

Open Box - Atomos Ninja V+ 5.2" 8K HDMI H.265 Raw Recording Monitor

R 15,995.00
R 15,995.00 R 19,995.00
Tax included. Shipping calculated at checkout.

DEMO062

Up to 20% off
Low stock

Choose PayGate at checkout for MobiCred Payments.

SHORT DESCRIPTION

  • 1920 x 1080 Touchscreen Display
  • HDMI 2.0 Input/Output
  • Record up to 8K30 ProRes Raw with cameras such as Canon R5
  • H.265 Codec Download License Included
    Open Box - Atomos Ninja V+ 5.2" 8K HDMI H.265 Raw Recording Monitor

    R 15,995.00

    Atomos Ninja V+ 5.2" 8K HDMI H.265 Raw Recording Monitor is the same as the previous generation Ninja V, the new Ninja V+ has a 5.2" display as well as records and plays back up to 8K to and from dedicated mini-SSDs.
    Straight from the sensor, it can record Apple ProRes raw up to 8K30 or DCI 4K120, and certain cameras such as the R5.

    The Atomos Ninja V+ 5.2" 8K HDMI H.265 Raw Recording Monitor offers a 10-bit screen with 1000 cd/m‚² AtomHDR technology which provides accurate monitoring of log gamma footage. Also support for log formats from Sony, Canon, Nikon, JVC, Panasonic, RED, and Z CAM cameras.

    Supported Log Formats

    • ARRI Log C
    • Canon C-Log, C-Log 2
    • FUJIFILM F-Log
    • JVC J-Log
    • Nikon N-Log
    • Panasonic V-Log
    • RED LogFilm
    • Sony SLog2, SLog3

    HDR Recording (Gamut)

    • ARRI Log CEI160, CEI200, CEI250, CEI320,
    • ARRI LogCEI400, CEI500, CEI640, CEI800
    • ARRI LogCEI1000, CEI1280, CEI1600
    • Canon C-Log, C-Log 2, C-Log3
    • FUJIFILM F-Log
    • HLG
    • JVC J-Log1
    • Nikon N-Log PQ10K
    • Panasonic V-Log<//li>
    • RED LogFilm, RG310, RG312
    • Sony SLog2, SLog3

    HRD Monitoring (Gamma)

    • ARRI ALEXA Wide Gamut
    • BT.2020
    • Canon Cinema, DCI P3, DCI P3+, BT2020
    • JVC LS300
    • Nikon N-Log PQ10K
    • Panasonic V-Gamut
    • Rec. 709
    • RED DRAGONcolor, DRAGONcolor2
    • REDcolor2, REDcolor3, REDcolor4
    • REDWideGamut
    • Sony S-Gamut, S-Gamut3, S-Gamut3.Cine
    • Sony SLog2, SLog3

    HRD Monitoring (Gamut)

    • ARRI ALEXA Wide Gamut (mapping to Rec. 709/BT.2020/DCI-P3 on loop-out)
    • BT.2020
    • Canon Cinema
    • DCI-P3, DCI-P3+
    • Panasonic V-Gamut
    • Rec. 709
    • RED DRAGONcolor, DRAGONcolor2
    • REDcolor2, REDcolor3, REDcolor4
    • REDWideGamut
    • Sony S-Gamut, S-Gamut3, S-Gamut3.Cine

    Time-Lapse

    Time-lapse can record to a single file, in ProsRes, DNx and ProRes Raw over HDMI or SDI.
    Time-Lapse sequence include:

    • Number of frames/seconds captured
    • Intervals between frames/seconds/minutes/hours
    • Duration of sequence in frames/seconds/minutes/hours

    Monitor Leica L-Log Gamma in BT2020 Gamut

    • Supports Leica SL 25 only
    • Support for other models available in future updates

    Atomos Ninja V+ 5.2" 8K HDMI H.265 Raw Recording Monitor

    • Master Caddy II
    • Battery Eliminator/Dummy Battery
    • Power Adapter
    • Neoprene Sleeve
    • Hard Case

    Display

    Panel Type IPS-Type LCD
    Display Size 13.2 cm
    Resolution 1920 x 1080
    Aspect Ratio 19:9
    Touchscreen Yes
    Maximum Brightness 1000 sd/m2
    Bit Depth / Color Support 8-Bit+FRC (1.07 Billion Colors)
    HDR Compatibility Advanced HDR
    Pixels Per Inch (ppi) 423 ppi
    Color Gamut 100% Rec.709
    Real-Time LUT Monitoring SDR
    Image Controls Anamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Pixel Zoom, RGB Parade, Scaling, Vectorscope, Waveform, Zebra

    I/O

    Video 1 x HDMI Type A (HDMI 2.0) Input
    1 x HDMI Type A (HDMI 2.0) Output
    Embedded Audio HDMI: 2-Channel
    HDMI: 8-Channel
    Audio 1 x 1/8" / 3.5 mm Mic/Line Input
    1 x 1/8" / 3.5 mm Headphone Output
    Built-In Speaker None
    Power 1 x D-Tap Input
    Other I/O 1 x LANC (2.5mm)
    Media/Memory Card Slot None

    Format Support

    Video Format HDMI (8/10-Bit 4:2:2)
    8K Raw: 30
    4K Raw: 120/60/30
    DCI 4K: 120/60/50/30/25/24
    UHD 4K: 60/50/30/25/24
    1080p: 120/60/50/30/25/24
    1080i: 60/50
    720p: 60/50
    Gamma Curve Rec709
    Video Signal Conversion HDMI to SDI
    DCI 4K: 60/50/30/25/24
    UHD 4K: 60/50/30/25/24
    1080p: 120/100/60/50/30/25/24
    1080i: 60/50
    720p: 60/50
    Timecode Support Yes

    Recording

    Pulldown Conversion 2:2, 3:2
    Camera Trigger HDMI
    Pre-Roll Record 4K: 2 Seconds
    Full HD: 8 Seconds
    Encoding Formats Up to 7680 x 4320
    ProRes 422, HQ, LT, Raw, Raw HQ 8/10-Bit 4:2:2 at up to 120 fps
    H.265 422 10-Bit 4:2:2 at up to 120 fps
    H.265 422 8/10-Bit 4:2:0 at up to 120 fps
    DNxHR HQ, HQX, LB, SQ 8/10-Bit
    Maximum Audio Tracks 12
    Metadata Tagging 10

    Power

    DC Input Power 6.2 to 16.8 VDC
    Built-In Battery None
    Battery Type 1 x L-Series
    Power Consumption 10 W (Typical)
    22 W (Maximum)

    Mounting

    Mounting 2 x 3/8"-16 Female

    Environmental

    Operating Temperature 40°C

    General

    Material of Construction Aluminum, Polycarbonate
    Dimensions 151 x 91.5 x 31.5 mm
    Weight 360 g
