Roland VP-42H Video Processor 4 x 1 HDMI
Choose PayGate at checkout for MobiCred Payments.
- 4 x HDMI Inputs / 1 x HDMI Output
- Supports up to 1080p/60 and WUXGA/60
- Fluid, Motion-Based Scene Switching
- 1 x PiP with Keyer & 3 x PiP Functions
Orms Cape Town
Roland VP-42H Video Processor 4 x 1 HDMI
Orms Cape Town
Shop 5, Roeland Square, Roeland Street
Gardens
Cape Town
Western Cape
8001
South Africa
Choose options
Choose PayGate at checkout for MobiCred Payments.
- 4 x HDMI Inputs / 1 x HDMI Output
- Supports up to 1080p/60 and WUXGA/60
- Fluid, Motion-Based Scene Switching
- 1 x PiP with Keyer & 3 x PiP Functions
Choose PayGate at checkout for MobiCred Payments.
- 4 x HDMI Inputs / 1 x HDMI Output
- Supports up to 1080p/60 and WUXGA/60
- Fluid, Motion-Based Scene Switching
- 1 x PiP with Keyer & 3 x PiP Functions
The Roland VP-42H Video Processor provides everything you need, all on one single screen, by layering and arranging multiple video sources via the four HDMI sources- being the ideal system for effective and engaging presentations, conferences, and digital signage.
Using minimum effort, the Roland VP-42H Video Processor still delivers maximum effect and never lets you down. It provides you with a variety of functions that enables you to instantly switch between scenes containing preset arrangements of layered sources in customisable inset windows. It also delivers really smooth transitions between the current and the next scene by automatically moving and resizing the windows into their next positions. The advanced Roland VP-42H also functions as a true cross-dissolve seamless switcher, with a keyer to create overlays and the ability to present still images via a USB drive.
Key features include flexible audio capability that includes stereo RCA outputs for de-embedding audio from connected HDMI sources and outputting it then to other devices such as speakers and mixers; and each of the input layers can be cropped, scaled, zoomed and positioned by easily clicking and dragging. Having it large event presentations is ideal as it makes a great impact at corporate events, as it provides 10-bit 4:4:4 video processing for pixel accurate colour, sharp and clear detail for the audience to read, and impress the viewers with smooth and dynamic motion scene switching. Not only is it just great for corporate events, but also does it excel on Digital Signages, Meeting Rooms; and it's a highly flexible multi-viewer for video production.
- Roland VP-42H Video Processor 4 x 1 HDMI
- AC Adapter
- Power Cord
- 4 x Rubber Feet
- Rackmount Angle Set
Processing | 4:4:4 (Y/Pb/Pr, RGB), 10-Bit 4:2:2 (Y/Pb/Pr), 10-Bit |
Input Connectors | 4 x HDMI Type A |
Output Connectors | 1 x HDMI Type A (Program) 1 x HDMI Type A (Menu) |
HDCP Compliant | Yes |
Supported Formats & Resolutions | 1080p: 59.94/50 1080i: 59.94/50 720p: 59.94/50 576p: 50* 576i: 50* 480p: 59.94* 480i: 59.94* 1920 x 1200/60 RB, 1920 x 1080/60 1600 x 1200/60 1400 x 1050/60** 1366 x 768/60** 1280 x 1024/60**, 1280 x 800/60**, 1280 x 720/60** 1024 x 768/60** 800 x 600/60* |
Effects | Layers: x 4 PiP with Keyer: x 1 PiP: x 3 |
Still Image Support | Internal Memory: x 1 Maximum Size: 1920 x 1200 Pixels Format: Windows Bitmap File (.bmp), 24 bpp, Uncompressed |
Sample Rate | 48 kHz, 24-Bit |
Input Connectors | 4 x HDMI Type A 1 x RCA Stereo |
Output Connectors | 2 x HDMI Type A* 1 x RCA Stereo 1 x 1/8" / 3.5 mm Headphone Stereo |
Input Level | -10 dBu (Maximum: +8 dBu) |
Input Impedance | 15 kOhms |
Output Level | Audio Output: -10 dBu (Maximum: +8 dBu) Headphone Output: 72 mW + 72 mW (32 Ohms) |
Output Impedance | Audio Output: 1 kOhm Headphone Output: 10 Ohms |
Format | HDMI: Linear PCM, 24-Bit, 48 kHz, 2-Ch |
Processing | Mixer: 4-Ch (Maximum Delay: 250 ms) |
External Connectors | Remote: 1 x RS-232, DB-9 (Male) LAN: 1 x RJ45 USB: 1 x USB Type-A (Future Expansion) USB Memory: 1 x USB Type-A |
Functions | Scene Memory: x 10 Test Pattern Generator Test Tone Generator EDID Emulator |
Power Supply | AC Adapter |
Current Draw | 2.1 A |
Power Consumption | 25 W |
Operating Temperature | 0 to 40°C |
Dimensions (WxDxH) | 242 x 125 x 44 mm |
Weight | 1.2 kg |
