Roland

Roland VR-1HD AV Streaming Mixer

Regular price R 30,495.00
Sale price R 30,495.00 Regular price
Tax included. Shipping calculated at checkout.

VR-1HD

Out of stock

Sorry, it's out of stock.

But we can let you know when it's back in.

SHORT DESCRIPTION

  • 3 x HDMI Inputs, 3 x HDMI Outputs
  • Stream up to 1080p30 Video, USB Type-B
  • NTSC/PAL, HD, Computer Signal Compatible
  • 2 x XLR/1/4" TRS Combo Mic Inputs

Payment methods

    The Roland VR-1HD AV Streaming Mixer is the perfect companion for content creators who's seeking maximum engagement in real time, where livestreaming outperforms uploaded video by a margin. The advanced streaming switcher from Roland allows you to broadcast dynamic multi-camera live streams, complete with amazing picture and sound that easily outclasses the usual live streams from a mobile device or any static webcam.

    Advanced features to this powerful Roland VR-1HD AV Streaming Mixer include three HDMI inputs where each one of them accepts a variety of HD and computer-based video resolutions, from cameras, gameplay, presentations and even smartphones; built-in Scene Switching that instantly jumps between scenes that contain preset arrangements of layered sources, displayed within customisable inset windows - which can be done by setting it up in advanced which can then be recalled via the five scene preset buttons to make your livestreaming so much more interesting.
    It also has built-in effects that lets you stand out from the rest of the crowd, which include Chroma Keying and green screens - allowing you to place your subject in front of a background that isn't really there and is a high-end visual effect that's seen in movies and used by weather people.

    Having three Auto Switching modes built-in allows you to control the Roland VR-1HD AV Streaming Mixer all by yourself, when presenting a livestreamed vlog or with a live music performance. The streaming switcher packs more advanced features inside where it acts as a video director - allowing it to switch cameras based on who's speaking into their microphone, and if both people are talking at once, the Roland VR-1HD will then switch to a wide shot showing both presenters.



    • Three HDMI inputs that accept HD and computer video resolutions
    • Two-studio quality XLR microphone inputs and line input
    • Mic input for a goose neck microphone making it easy for hands-free and headset-free performances
    • Scene switching functionality, with five pre-set scenes that can be included in any live stream
    • Audio Effects functionality allows sound effects, jingles and theme songs in videos/performances
    • Auto Switching modes make it easy to put on a one-person show
    • Functions as its own audio engineer with automatic mixing functions and built in equalizers, gates and compressors to balance out changes in volume when speaking or singing to ensure professional sound performance
    • Voice Changer effect from Rolands VT series of Voice Transformers can instantly transform any performers sound
    • Stream performances and presentations easily through a computers USB 3.0 ports

    • Roland VR-1HD AV Streaming Mixer
    • AC Adapter
    • Power Cord

    Video
    Video Processing 4:2:2 (YPbPr), 10-Bit
    Input Connectors HDMI: 3 x HDMI Type A (HDCP, Multi-Format Support)
    Output Connectors Main: 1 x HDMI Type A (HDCP Support)
    Monitor: 1 x HDMI Type A (HDCP Support)
    Thru: 1 x HDMI Type A (HDCP Support)
    Video Input Formats Input Conforms to SMPTE-296M/274M
    1080p: 59.94/50
    1080i: 59.94/50
    720p: 59.94/50
    576p: 50
    576i: 50
    480i: 59.94

    60 Hz
    WUXGA (1920 x 1200)
    FHD (1920 x 1080)
    UXGA (1600 x 1200)
    SXGA+ (1400 x 1050)
    FWXGA (1366 x 768)
    SXGA (1280 x 1024)
    WXGA (1280 x 800
    HD (1280 x 720)
    XGA (1024 x 768)
    SVGA (800 x 600)
    VGA (640 x 480)

    Note: The Refresh Rate Is the Maximum Value of Each Resolution.
    Conforms to VESA DMT Version 1.0 Revision 11.
    1920 x 1200, 60 Hz: Reduced Blanking.
    The Frame Rate Can Be Selected at the System Menu (59.94 or 50 Hz).
    Video Output Formats Main, Monitor
    1080p: 59.94/50
    1080i: 59.94/50
    720p: 59.94/50

    60 Hz
    WUXGA (1920 x 1200) *
    FHD (1920 x 1080) *
    UXGA (1600 x 1200) *
    SXGA+ (1400 x 1050) *
    FWXGA (1366 x 768) *
    SXGA (1280 x 1024) *
    WXGA (1280 x 8000) *
    XGA (1024 x 768) *
    VGA (640 x 480) *

    Note: The Video Signal Frame Rate Can Be Selected at the System Menu (59.94 or 50 Hz).
    * Output Refresh Rate Is 75 Hz When Frame Rate Is Set to 50 Hz.

    USB Stream
    1080p: 29.97/25
    720p: 59.94/50/29.97/25
    854 x 480p: 59.94/50/29.97/25

    Note: The Video Signal Frame Rate Can Be Selected at the System Menu (59.94 or 50 Hz).
    Still Image Maximum Size: 1920 x 1200 Pixels
    Format: Windows Bitmap File (.bmp) 24-Bit per Pixel, Uncompressed

    Note: Up to Two Files from USB Can Be Loaded at Startup.
    Video Effects Scene: PiP, Split
    Transition: Black Fade, Mix Fade
    Key Composition: Luminance Key
    Other: Still Image Playback, Output Fade (Audio, Video: White or Black), Test Pattern Output
    Audio
    Audio Processing 48 kHz, 24-Bit
    Audio Formats HDMI Inputs 1-3: Linear PCM, 48 kHz, 24-Bit, Stereo
    USB Stream: Linear PCM, 48 kHz, 16-Bit, Stereo
    Input Connectors Video Inputs 1-3: 3 x HDMI Type A
    Mic In 1-2: Combo 3-Pin XLR, 1/4" TRS Phone (+48 VDC, 10 mA Max. Phantom Power)
    Line In: 2 x Stereo RCA Phono
    USB Stream: USB Type-B
    Output Connectors Main: HDMI Type A
    Monitor: HDMI Type A
    Line Out: RCA Phono Type
    USB Stream: USB Type-B
    Headphones: Stereo Miniature Phone Type
    Nominal Input Level Mic In 1/2: -60 to +4 dBu (Maximum Input Level: +22 dBu)
    Line In: -10 dBu (Maximum Input Level: +8 dBu)
    Input Impedance Mic In 1/2: -Minimum 10 kOhms (Balanced, Head Amp Gain: 0 to +17 dBu), Minimum 5 kOhms
    Line In: -10 dBu (Maximum Input Level: +8 dBu)
    Nominal Output Level Line Out: -10 dBu (Maximum Input Level: +8 dBu)
    Headphones: 92 mW + 92 mW (32 Ohms)
    Output Impedance Line Out: 1 kOhms
    Headphones: 10 Ohms
    Audio Effects Auto Mixing, Echo Canceller, Howling Canceller
    EQ, Delay, Compressor, HPF, Gate
    Reverb, Limiter, Voice Changer
    Player 4 x Audio Players
    Data Format: WAV (Linear PCM, 48 kHz, 16-Bit Stereo/44.1 kHz, 16-Bit, Stereo)
    General
    Other Connectors USB Memory: 1 x USB Type-A (For USB Flash Drive, Still Image, Audio Player, System Update)
    USB Stream: 1 x USB Type-B (For USB 3.0 Video, USB 2.0 Audio Stereo):
    1 In/1 Out, Remote Control
    DC Input: 1 x Barrel
    Functions 5 x Scene Memory
    Panel Lock Function
    EDID Emulator
    Auto Switching (Auto Scan, Beat-Sync Switching, Video Follow Audio)
    AC Adapter Current Draw: 2 A
    Power Consumption: 24 W
    Operating Temperature 0 to 40°C
    Dimensions (WxDxH) 31.4 x 16.9 x 6.6 cm
    Weight 1.6 kg
