The SmallRig 145W 4-Port USB-C Wall Power Adapter is designed to allow you to charge multiple power-hungry devices at once. 145W of total power is shared between the four USB-C ports.
USB-C1 and USB-C2 with PD 3.1 ports individually can receive up to 140W. While the USB-C3 and USB-C4 can receive up to 45W max power. This combination on the SmallRig 145W 4-Port USB-C Wall Power Adapter allows you to simultaneously charge a mixture of smaller and larger devices at once, or alternatively, one single extremely high power-capacity device.
The SmallRig 145W 4-Port USB-C Wall Power Adapter provides a variety of safety precautions to keep any device safe that you plug into the adapter. It features short circuit and overcurrent protection built into each port.
Power Output Modes
Depending on which ports you use individually or together, the maximum power output of the SmallRig 145W 4-Port USB-C Wall Power Adapter can fluctuate considerably. Please note that regardless of which combination you choose, there is a maximum shared output of 145W.
- USB-C1 or USB-C2: Up to 140W
- USB-C3 or USB-C4: Up to 45W
- USB-C1 and USB-C2: Up to 100W
- USB-C3 and USB-C4: Up to 20W
- USB-C1 or USB-C2 and USB-C3 or USB-C4: Up to 100W on C1 or C2, and up to 45W on C3 or C4
- USB-C1 and USB-C2 and USB-C3 or USB-C4: Up to 65W on C1, up to 30W on C2, and up to 45W on C3 or C4
- USB-C1 or USB-C2 and USB-C3 and USB-C4: Up to 100W on C1 or C2, and up to 20W on C3 or C4
- All Ports: Up to 65W on C1, up to 30W on C2, and up to 20W on C3 and C4
SmallRig 145W 4-Port USB-C Wall Power Adapter
| Power Outputs | |
| Plug Type | |
| Max Combined Power Output | |
| Fast Charging Technology | |
| Included Cable | |
| Dimensions | |
| Weight |
